Directory

1.The difference between rapid impact compaction and dynamic compaction

2.Features of Rapid Impact Compaction

The difference between rapid impact compaction and dynamic compaction

Rapid impact compaction and dynamic compactors are two different types of equipment. Their working principle is to convert kinetic energy into impact energy to compact the soil, but with different strokes and frequencies. The frequency of the rapid impact compactor is fast, up to about 30 times per minute, while the stroke of the dynamic compactor can reach more than 10 meters, and the frequency is extremely low, which can be regarded as a single pulse. The soil compaction method can be called dynamic consolidation method or dynamic compaction method, and the operation is realized by the hydraulic and PLC automatic control function of the loader or excavator.

The dynamic compaction machine uses mechanical power to freely drop heavy hammers of several tons to dozens of tons from a few meters to tens of meters. Dynamic pressure is applied to the soil to force the soil to compact, reduce the compressibility and increase the strength. This reinforcement method is called dynamic compaction in the industry, and is mainly suitable for coarse-grained soils with a particle size greater than 0.05mm, such as sand, gravel soil, mountain skin soil, fly ash, miscellaneous fill, backfill, low-saturated powder Soil, clay, slightly expansive soil and collapsible loess have no obvious reinforcement effect on saturated silt and clay.

Features of Rapid Impact Compaction

The tonnage of the rapid impact compaction is small, but the working hammer falls freely, but it also has the function of hydraulic boosting auxiliary efficiency. The working area of the hammer is small, and it will also form a larger impact (the compaction force of individual large rapid impact compaction machines will exceed that of small hydraulic tamping machines), Therefore, rapid impact compactor are also called hydraulic compactors or light hydraulic compactors.

High amplitude and high frequency compaction modes are possible

The depth of the impact compaction of the hydraulic compactor is inclined to its large amplitude compaction. The rapid impact compaction usually has three large, medium and small stroke gears. The rapid impact compaction has high compaction frequency during construction in small gears. The rapid impact compaction refers to the high frequency, which is also conducive to foundation compaction.

Large tonnage compaction in tight locations

Before the application of rapid impact compactors, the foundation compaction of some narrow stations usually only use small rapid impact compactors such as vibration compaction, frog compaction or even manual compaction. Amplitude compaction and high frequency compaction modes can be switched at any time to meet different compaction needs.
